Factory package
General description of our wooden house factory package
| SUPPLY The supply and assembly of the components of the house are understood to be for the UNFINISHED BUILDING AT AN ADVANCED STAGE with TRUSSED RAFTER ROOF | TYPE OF HOUSE Wooden House |
| ENERGY RATING Almost passive house energy
rated A+ or above | NOISE RATING Class 1 |
| STRUCTURAL RATING Timber building with seismic
resistance class 1 | WALLS Framed external bearing wall structure finished with external wood fibre render with thermal performance coefficient equivalent to: U = 0.135 W/m2 |
| ROOF WITH EXPOSED BEAMS The roof with exposed beams supplied has a thermal performance coefficient equivalent to: U = 0.18 W/m2 | STRUCTURES IN SOLID AND/OR LAMINATED WOOD The solid and/or laminated wood structures meet the requirements set out in clause A of section 11.1 of NTC 2018 standards (CE marking of structural elements) |
| WINDOWS All the windows and patio doors are triple glazed with double cavity and have Class S profiles (as specified in standard EN 12608). They also have a very high radiation resistance value (12 GJ/m2), well above the limit stipulated by the standard | GUARANTEE The structural guarantee is for ten years |
Supply and assembly of the external walls
Wooden cladding 21 x 145 UYVk Spruce AB - horizontal
Air circulation chamber
28x45 mm wooden counter-battens
Breathable waterproof membrane 0.5 mm thick Riwega USB WALL 100
Wooden post structure C24 - 200mm, wall height 2500mm
Thermal insulation, total thickness 200 mm
Vapour barrier 0.2 mm
Horizontal laths 45x45mm – not included in the price
OSB Plate 12mm – not included in the price
Plaster Board 13mm – not included in the price
Supply of internal walls
SUPPLY AND ASSEMBLY OF THE INTERNAL WALLS INCLUDES:
Structure of the walls with wooden posts 45 mm thick, of variable widths (95/145/195 mm)
Supply of trussed rafter roof
THE ON-SITE SUPPLY AND INSTALLATION OF THE STRUCTURE FOR THE CREATION OF THE ROOF INCLUDES:
Supporting beams with roof trusses in accordance with the structural calculations
Breathable membrane / RIWEGA DO 135
28 X 45 mm battens
From 1 to 6 – included in the price
From 7 to 15 – NOT included in the price
ALL THE SOLID AND/OR LAMINATED TIMBER STRUCTURES MEET THE REQUIREMENTS
SET OUT IN CLAUSE A) OF SECTION 11.1 OF THE NTC 2018 STANDARDS
(CE MARKING OF STRUCTURAL ELEMENTS)
Supply and installation of all windows and window doors
Included in the price are positions A and TU – from windows specification
Positions: VU and LU are not included in the price
Roof windows are not included in the price
THE SUPPLY OF WINDOWS AND PATIO DOORS IS AS FOLLOWS:
PVC, in white or in a colour selected from our catalogue – colour windows costs extra
Triple glazing with double cavity
Class S profiles
Radiation resistance coefficient equivalent to 12 GJ/m2
Thermal performance coefficients
Uw value = up to 0.50 W/(m2K)
Uf value = 0.95 W/(m²K)
WINDOW DOORS HIGHER THAN 210 WILL BE SUBJECT TO A SURCHARGE
sliding doors / sliding windows are not included in the price
Windows assembly:
Fixed only with clips
Not taped, without window mouldings, without window sills
